Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere

1 adet
MOQ
$0.50 - $10.00/pieces
fiyat
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere
Özellikleri Fotoğraf Galerisi Ürün Açıklaması Fiyat talebi
Özellikleri
Teknik Özellikler
Type: Clear Quartz Plate
Uygulama: Yarı iletken, optik
Thickness: 0.5-100mm
Şekli: Karesi
Processing Service: Bending, Welding, Punching, polishing
Ürün Adı: kuvars levha
Material: SIO2>99.99%
yoğunluk: 2,2 gr/cm3
Çalışma Sıcaklığı: 1150°C
Sertlik: Mors 6.5
Erime Noktası: 1750-1850°C
Asit toleransı: Seramikten 30 kat, paslanmaz çelikten 150 kat
Boyut: Özel
tavlama noktası: 1180°C
Gerilme noktası: 1100°C
Liman: Şangay ve Qindao limanı
Vurgulamak:

Profesyonel özel kuvars penceresi

,

Optik kuvars penceresi

,

Yüksek geçirgenlikli kuvars penceresi

Temel bilgiler
Menşe yeri: Jiangsu.Çin
Marka adı: ShengFan
Sertifika: ROSH SGS
Model numarası: QSP-1
Ödeme & teslimat koşulları
Packaging Details: plastic bubble/ polystyrene foam sheet/ carton/ wooden pallet
Yetenek temini: Ayda 10000 parça/parça
Ürün Açıklaması


Shengfan Quartz plate characteristic

*Brand shengfanquartz
*SIO2 99.99%
*Density 2.2(g/cm³)
*Degree of hardness moh’ scale 6.6
*Melting point 1732℃
* Working temperature 1100℃
*Annealing point 1180℃
*Softening point 1630℃

Setting Information
Color Transparent
Shape Circular / Round
Standard JGS1,JGS2,JGS3
Material 99.99% sio2
Diameter 1-800mm
Thickness 0.2-100mm
Application Optics quartz windows
Density  6.6
Light Transmittance >92%
Hardness Mose 6.5
Resistance Value 1000 times than ordinary glass
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 0

How to customize?



1.Make drawings of the dimensions
2.Make products for drawing
Unit: mm
Remarks:In addition there are requirements such as tolerance, polish, translucency, etc. can beprovided according to demand.
We can customize any size quartz glass plate according to your drawing.
【Application scope】:Used to make semiconductors, electric light source device, semi-conductor communication devices, lasers,
optical instruments, laboratory instruments, electrical equipment, medical equipment and chemical instruments, chemical industry,
electronics, metallurgy and other industries.
【Product advantages】: not easy to be corroded, can withstand high temperature, beautiful appearance, compact structure, easy to operate, strong light transmission, good electrical insulation.
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 1
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 2Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 3Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 4Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 5Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 6Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 7
Production process:
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 8
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 9Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 10
Application:
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 11
Product use:
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 12
Packing & Delivery​:
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 13
Company Introduction:
Lianyungang Shengfan Quartz Product Factory is a professional manufacture specialized in research and development of quartz plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital - Donghai City, Jiangsu Prov., China. 70 km far from Lianyungang port, convenient transportation.
Covering an area of 1000 square meters,we now have over 30 employees,an annual sales figure exceeding USD 5.2 million.
With the philosophy of Technology Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to establish an international enterprise with standard and sustainable operation capability.
Profesyonel Özel Yüksek İletişimli Optik Kuvars Pencere 14
Our Services & Strength
The company adhere to the integrity of business, experience, reasonable price, quality assurance, to provide excellent after-sales service, we sincerely welcome customers to come to negotiate.

FAQ:
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the delivery time?
A:Within 15 days after receiving deposit.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How to proceed an order in your factory?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q5. How do you ship the goods and how long does it take to arrive?
DHL, UPS, FedEx or TNT are optional for small order. It usually takes 3-5 days to arrive.
Airline and sea shipping are also available.
